Analog-to-digital converter (ADC)

RM0008

11.12.2

ADC control register 1 (ADC_CR1)

Address offset: 0x04

Reset value: 0x0000 0000

31

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

Reserved

AWDEN JAWDEN

Reserved

DUALMOD[3:0]

Res.

rw

rw

Res.

rw

rw

rw

rw

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

DISCNUM[2:0]

JDISCE

N

DISC

EN

JAUTO

AWD

SGL

SCAN JEOC IE AWDIE

EOCIE

AWDCH[4:0]

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

rw

Bits 31:24

Reserved, must be kept cleared.

Bit 23 AWDEN: Analog watchdog enable on regular channels

This bit is set/reset by software.

0: Analog watchdog disabled on regular channels

1: Analog watchdog enabled on regular channels

Bit 22 JAWDEN: Analog watchdog enable on injected channels

This bit is set/reset by software.

0: Analog watchdog disabled on injected channels

1: Analog watchdog enabled on injected channels

Bits 21:20

Reserved, must be kept cleared.

Bits 19:16 DUALMOD[3:0] : Dual mode selection

These bits are written by software to select the operating mode.

0000: Independent mode.

0001: Combined regular simultaneous + injected simultaneous mode

0010: Combined regular simultaneous + alternate trigger mode

0011: Combined injected simultaneous + fast interleaved mode

0100: Combined injected simultaneous + slow Interleaved mode

0101: Injected simultaneous mode only

0110: Regular simultaneous mode only

0111: Fast interleaved mode only

1000: Slow interleaved mode only

1001: Alternate trigger mode only

Note: These bits are reserved in ADC2 and ADC3.

In dual mode, a change of channel configuration generates a restart that can produce a

loss of synchronization. It is recommended to disable dual mode before any

configuration change.

Bits 15:13 DISCNUM[2:0] : Discontinuous mode channel count

These bits are written by software to define the number of regular channels to be converted

in discontinuous mode, after receiving an external trigger.

000: 1 channel

001: 2 channels

.......

111: 8 channels

220/995

Doc ID 13902 Rev 9
